8CH 4K POE 15.6'' LCD NVR COMBO
8CH 4K POE 15.6'' LCD NVR COMBO
Normale prijs
€680,00 EUR
Normale prijs
Aanbiedingsprijs
€680,00 EUR
Eenheidsprijs
/
per
Verzendkosten worden berekend bij de checkout.
Kan beschikbaarheid voor afhalen niet laden
Technical Parameters
|
Model
|
NVR3108-P8-S3JL
|
|
Decoding
|
|
|
Decoding Format
|
Ultra 265, H.265, H.264
|
|
Decoding Capability
|
1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25, 6 x 1080P@30, 8 x 720P@30
|
|
Audio Compression
|
G.711A, G.711U
|
|
Network
|
|
|
Incoming Bandwidth
|
64Mbps
|
|
Outgoing Bandwidth
|
48Mbps
|
|
Remote Users
|
128
|
|
Protocols
|
TCP/IP;P2P;UPnP;NTP;DHCP;PPPoE;HTTP;HTTPS;DNS;DDNS;SMTP;RTSP
|
|
Browser(Plugin)
|
Windows:IE(IE10/11), Firefox (version 52.0 and above), Chrome(version 45 and above), Edge(version 79 and above)
|
|
Display
|
|
|
Monitor
|
15.6’’ LCD Screen(Resolution:1080P)
|
|
Video/Audio Input
|
|
|
IP Video Input
|
8 ch
|
|
Video/Audio Output
|
Description
|
|
HD-MI Output
|
HD-MI:4K(3840x2160)/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
|
|
RCA Audio Output
|
1 ch
|
|
Liveview Display
|
1/4/6/8/9
|
|
Corridor Mode Screen
|
3/4/5/7/9
|
|
Snapshot
|
|
|
FTP/Schedule/Event Snapshot
|
1ch snapshot, up to D1 resolution
|
|
Recording
|
Description
|
|
Recording Resolution
|
8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF
|
|
Synchronous Playback in Local
|
8ch
|
|
Smart
|
|
|
VCA Detection by IPC
|
Face Detection;SIP(Intrusion Detection, Cross Line Detection, Enter Area, Leave Area);Ultra Motion Detection(UMD)
|
|
VCA Search
|
Behavior Search
|
|
Smart by IPC
|
Total 4 ch(Face Detection, SIP, UMD)
|
|
Alarm
|
|
|
General Alarm
|
Auto Tracking;Motion Detection;Tampering;Human Body Detection;Video Loss;Alarm Input;Audio Detection
|
|
Alert Alarm
|
IP Conflict;Network Disconnected;Disk Offline;Disk Abnormal;Illegal Access;Hard Disk Space Low;Hard Disk Full;Recording/Snapshot
Abnormal |
|
GUI Language
|
|
|
GUI Language
|
21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese,
French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian |
|
Hard Disk
|
|
|
SATA
|
1 SATA Interface
|
|
Capacity
|
Up to 10TB for each HDD
(The maximum HDD capacity varies with environment temperature and hard disk size)
|
|
External Interface
|
|
|
Network Interface
|
1 RJ45 10M/100M selfadaptive Ethernet Interface
|
|
USB
|
Rear panel: 2 x USB2.0
|
|
RS485
|
N/A
|
|
RS232
|
N/A
|
|
Alarm In
|
N/A
|
|
Alarm Out
|
N/A
|
|
Power Supply
|
DC 52V/1.8A
|
|
PoE
|
|
|
Interface
|
10M/100M selfadaptive Ethernet Interface
|
|
MaxPower
|
Max 30W for single port, Max 75W in total
|
|
Supported Standard
|
IEEE 802.3at, IEEE 802.3af
|
|
Working Environment
|
|
|
Working Temperature
|
-10 °C ~ 55 °C (14 °F ~ 131 °F)
|
|
Working Humidity
|
≤ 90% RH (noncondensing)
|
|
Power Consumption
(without HDD)
|
≤ 9W
|
|
Certification
|
|
|
Certification
|
CE;FCC;UL;RoHS;WEEE
|
|
CE
|
EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035
|
|
FCC
|
Part15 Subpart B
|
